Pressing on with its One Seasonic Initiative, the PRIME TX, PRIME PX and PRIME GX series became the successors to the Seasonic PRIME and PRIME Ultra series.
The PRIME Series has always demonstrated outstanding performance and have become the epitome of technological excellence and quality through the years. This third generation of PRIME Series rolled out not only with a uniformed naming scheme but also with updated general design and connection cables. As each new model in these PRIME series have their distinctive set of features and specifications, prospective customers will find a streamlined buying guidance through understanding the One Seasonic process.
TECHNICAL SPECIFICATIONS
80PLUS® | Platinum |
Cybenetics Efficiency Level | TBA |
Cybenetics Noise Level | TBA |
Form Factor | Intel ATX 12 V |
Dimensions (L x W x H) | 210 x 150 x 86 mm |
Fan Size | 135 mm |
Fan Control | Premium Hybrid Fan Control |
Fan Bearing | Fluid Dynamic Bearing |
Life Expectancy | 50,000 hours at 40 °C, 15 % - 65 % RH |
Modularity | Fully Modular |
Cable type | Flat black cables |
Operating Temperature | 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
MTBF @ 25 °C, excl. fan | 150,000 hours |
AC Input | Full Range |
Protection | OPP, OVP, UVP, OCP, OTP, SCP |
Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC, CE |
Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH |
Warranty | 12 Years |
AC Input | Voltage: 100 V - 240 V Current: 15 - 10 A Frequency: 50 Hz - 60 Hz |
.
